Main features:
1. Support the cashbox
2. Easy paper-roll installation, Easy maintenance
3. Low consumption, low operation cost
4. Compatible with ESC/POS printing instruction set
5. Support for a variety of international language character
6. Mini Pos Printer, small size, saving space, easy to use on your desk
7. Pos Receipt Printer for Restaurant, Sales, Kitchen, Retail, etc
Product Specifications
Model | H58 |
---|---|
Printing Method | Thermal Receipt Printer – Not Label/Sticker |
Interface | USB Only |
Standard Accessories | Roll Paper x 1, CD-ROM (Drivers, Utility Software, Manuals), USB Cable, Power Cable |
Weight | 0.75kg |
Technical Specifications
Brand | Atpos |
---|---|
Font | 9×17 / 12×24, Hanji Font: 24×24, Thai Font: 9×24 / 12×24 |
Character Size (W x H) | 0.88×2.13mm / 1.25x3mm, Hanji Font: 3x3mm, Thai Font: 0.88x3mm / 1.25x3mm |
Character Set | 95 Alphanumeric, 18 set International, 128×43 pages (including user-defined page) Hanz Barcode: UPC-A, UPC-E, JAN13(EAN13), JAN8(EAN), CODE39, ITF, CODEBAR (NW-7), CODE93, CODE128, GS1-128, Gs1 DataBar Two-dimensional code: PDF417, QRCode, MaxiCode, 2D Gs1 DataBar Composite Symbology |
Characters Per Inch | 22.6cpi / 16.9cpi, Hanji Font: 7.8cpi, Thai Font : 22.6cpi / 16.9cpi |
Installation | Horizontal |
Buffer | 2048K bytes, NV Flash: 256K bytes |
Print Speed | Max 90mm/s |
Dot Density | 384dots/Line(8dots/mm,203dpi) |
Paper (Roll Paper (Width & Roll Diameter) | 57.5 ± 0.5 (W) × dia. 83.0 |
Power | DC +12V ± 5% |
Operating | Approx. 3A (Mean/Print ratio 18% with print pattern) |
Standby | Approx. 0.1A (Mean) |
Cash Drawer Power Supply | DC 12V 1A |
Cash Drawer Integration | Yes Supported |
Dimensions (D x W x H) | 185x115x130mm |
Printer Head Life | 100KM (Print Density <12.5) |
Cutter | Manual Blade 100,000 Times |
Warranty | 1 year |
